Multifunctional Windshifter

1) Windshifter is a device used to separate materials of different densities or shapes. It is often used in grain processing, seed processing, Chinese medicinal material screening, and some industrial production processes. Its working principle is based on the difference in the movement characteristics of materials in the airflow to achieve separation.

2) The following is an overview of the basic working principle of the windshifter:

1. Feeding:

The material first enters the wind separator through the feed port.

2. Airflow generation:

The Windshifter is equipped with a fan or other type of aerodynamic device that can generate a directional airflow. The direction and speed of the airflow can be adjusted as needed.

3. Material suspension and separation:

When the material enters the airflow, lighter impurities (such as dust, light debris, etc.) will be carried away by the airflow, while heavier, qualified materials will fall or move forward a less distance due to gravity.

By adjusting the speed and direction of the airflow, materials of different densities or shapes can be effectively separated.

4. Collection and discharge:

The separated materials will be collected in different collectors respectively. Usually, lighter impurities are discharged into a dust bag or similar container, while qualified materials are collected in another container or directly transported to the next processing link.

5. Recycling:

3)In some designs, the Windshifter is also equipped with a circulation system, so that the airflow can be reused, thereby improving energy efficiency.

The application of windshifter is very wide. In addition to the agricultural field, they are also used in industries such as plastic recycling and mineral processing. By precisely controlling the airflow parameters, the windshifter can efficiently complete the task of screening and purifying materials.
