The drum screen is a widely used device for domestic waste treatment. Its main function is to separate materials of different particle sizes and properties through a rotating cylinder. With the acceleration of urbanization, the amount of domestic waste generated is increasing, so it is particularly important to deal with these wastes efficiently and environmentally friendly.
First of all, the drum screen has good adaptability in design, and the aperture size can be adjusted according to actual needs to effectively screen out various types of solid waste. When the domestic waste is initially classified, large particles such as plastic bottles and large pieces of paper will be left on the surface, while smaller particles can pass through the mesh smoothly, thus achieving rough classification. This process not only improves the efficiency of subsequent processing, but also reduces labor costs.
Secondly, the drum screen can be used in conjunction with other equipment, such as crushers, air separators, etc., to achieve more comprehensive and detailed resource recovery. For example, the combustible part after preliminary screening can be further crushed into uniform small pieces by a crusher, and then the light materials can be removed by air separation technology to improve the quality of the combustibles. In addition, for non-recyclable or hazardous waste, the ideal effect can be achieved by accurately controlling the retention time, which is helpful for environmental protection.
Furthermore, due to its simple structure and convenient maintenance, it is easy for operators to master. At the same time, the equipment operates stably and is not prone to clogging, which is crucial for large-scale continuous operations. Regular cleaning and maintenance are also relatively simple, providing a guarantee for enterprises to reduce operational risks.
Finally, integrating advanced technology into traditional machinery, such as intelligent monitoring systems, can provide real-time feedback on working status and fault information, making management more scientific and efficient. Therefore, high-quality drum screens manufactured using modern production processes are an important tool for improving the disposal capacity of domestic waste and have played a positive role in promoting the development of the circular economy.
Trommel screen parameter:
Model | Length Range | Segment No. | Aperture Size | Power (Kw) | Inclined Angle | Max. Material Size | Rotating Speed(rpm) |
ZCφ600 | 2-4m | 1-2 | ≤30mm | 2.2-3 | 0-7° | 60mm | 12-18 |
ZCφ800 | 2-5m | 1-3 | ≤50mm | 3-5.5 | 0-7° | 100mm | 12-18 |
ZCφ1000 | 2-6m | 1-4 | ≤100mm | 4-11 | 0-7° | 150mm | 10-18 |
ZCφ1200 | 3-8m | 1-4 | ≤150mm | 5.5-18.5 | 0-7° | 200mm | 9-15 |
ZCφ1500 | 3-10m | 1-5 | ≤200mm | 7.5-22 | 0-7° | 250mm | 9-15 |
ZCφ1800 | 4-12m | 1-5 | ≤220mm | 7.5-22 | 0-7° | 270mm | 8-15 |
