Wood Pallet Shredder

Production Capacity:

1000-10000kg per hour

Applicable Industries:

Volume Reduction:

Power:

30kw*2

Core Components:

shaft blades

Place of Origin:

Henan, China

Wood pallet shredders are built to handle tough and bulky wood materials.

Email: sales@zchmachinery.com Get Latest Price

Product Details

Characteristics

Working Principle and Application

Parameters

Product Details

A wood pallet shredder is a machine designed to shred and reduce the size of wooden pallets and similar wood-based materials, such as crates, medium-sized wood scraps, and corrugated sheets and forms. This process is useful for recycling purposes, reducing the volume of wood waste, and preparing materials for further processing, such as creating wood pellets.

Characteristics

Efficiency: Capable of processing large volumes of wood pallets quickly and effectively

Versatility: Suitable for a wide range of wood types and sizes

Eco-Friendly: Helps in recycling and repurposing wood waste

Fully automatic : PLC electric control cabinet one click start

Working Principle and Application

Considerations When Choosing a Wood Pallet Shredder:

Material Type: Different wood types may require specific configurations or materials of construction.
Output Size: The desired size of the shredded material will determine the type of screen or grate used.
Throughput Capacity: The amount of material you need to process will influence the size and capacity of the shredder.
Maintenance Requirements: Regular maintenance, such as cleaning and blade replacement, is necessary to keep the shredder operating at optimal performance.

Parameters

Model	600	800	1000	1200	1400	1600	1800
Motor(kw)	11*2	18.5*2	35*2	45*2	55*2	75*2	110*2
Reducer	P6-P7	P7-P8	P8-P10	P10-P12	P11-P13	P12-P16	P14-P16
Siemens or other motors, planetary reducers or other reducers can be customized according to customer requirements
Rotation Speed	8-20rmp	8-20rmp	8-15rmp	8-15rmp	8-15rmp	8-12rmp	8-12rmp
Blades Diameter	220-320	260-320	260-400	400-500	400-500	500	500
Blades material	The material of the blades (55sicr, 5crsi, 9crsi, skd11, m6v, h13) can be customizedaccording to the customer's actual usage
Feeding Size	1200*900mm	1400*1000mm	1600*1200mm	1800*1300mm	2000*1300mm	2200*1700mm	2400*2000mm
The size and appearance of the feeding hopper can be customized according to thecustomer's feeding situation
Weight(kg)	1800	2500	3700	5500	7500	9500	13000

If you are looking for a machine that specifically shreds wood pellets, it would be more common to refer to this as a wood pellet mill or a machine that processes wood materials into wood pellets rather than shredding the pellets themselves. Please let me know if you need more information
