Ballistic separation is a step in the sorting process
which usually takes place after the material has
been sorted by size and density. Ballistic separators
represent versatile engineering solutions for
high-quality separation and sorting of materials
of various kinds, shapes and sizes. Easily adjustable
to rapidly changing waste environment, these
machines are perfect to handle future challenges
of the industry.
Versatility in types of waste to treat and multiple fraction separation
Ballistic separators are multifunctional machines
which allow to treat various types of waste: from
paper and lightweight packaging to construction
and demolition as well as municipal solid waste.
These machines are capable to divide material
stream into three fractions – heavier 3D fractions
such as tins or stones, lighter 2D or flat fractions
such as paper and film and small-sized fractions
which are screened down.
Ballistic separators ensure high purity, cleaner
output and require little maintenance which
results in low downtime.
BS04 | BS06 | BS08 | BS10 | BS12 | |
Paddy Number | 4 | 4 - 6 | 6 - 8 | 6 - 8 | 6 - 10 |
Paddle length | 5.5m | 5.5m | 5.5m | 5.5m | 5.5m |
Angle adjustment | 0 – 25° | 0 – 25° | 0 – 25° | 0 – 25° | 0 – 25° |
Sieve hole size | 20-80 mm | 30-80 mm | 30-80 mm | 30-80 mm | 30-80 mm |
Fan Number | 2 - 4 | 2 - 4 | 2- 4 | 2 - 4 | 2 - 4 |
Power | 5.5kw | 7.5kw | 11kw - 15kw | 11kw -18.5kw | 22kw |
Throughput | 0-30 m³/h | 30-50 m³/h | 50-70 m³/h | 70-90 m³/h | 90-120 m³/h |
