Uses of Double Shaft Shredder

Date:2024-12-26
View: Point

Uses of Double Shaft Shredder


Double shaft shredder is a mechanical device used for material crushing. Its main uses include:



Solid waste treatment: It can handle various types of solid waste, such as waste plastics, rubber products, wood, metal, etc., and is widely used in the environmental protection industry.

Recycling: In the field of resource recycling, double shaft shredders can tear waste items into smaller blocks or sheets, which is convenient for subsequent classification, cleaning and reprocessing.

Pretreatment process: For some materials that need further processing, such as the preparation of refuse-derived fuel (RDF), double shaft shredders can be used as pretreatment equipment to crush the raw materials to a suitable size.

Reducing volume: By tearing up large pieces of garbage or waste materials, their volume is effectively reduced, thereby reducing transportation costs and improving storage efficiency.

Special material processing: Some models of double shaft shredders can also handle special types of waste such as electronic waste and medical waste, and effectively dispose of them while ensuring safety.

Industrial production: In some industrial processes, such as waste paper processing in the papermaking industry, or the processing of waste tires in tire retreading plants, double shaft shredders are also an indispensable part.

Biomass conversion: For biomass materials such as agricultural waste and forestry residues, they can be better converted into bioenergy or other useful products after being processed by a double-shaft shredder.

When choosing a double-shaft shredder suitable for a specific application, factors such as the properties of the material to be processed (hardness, toughness, etc.), the expected output particle size, and production capacity requirements need to be considered. In addition, with the development of technology, new models of double-shaft shredders may also have the characteristics of higher efficiency, lower noise, and easier maintenance.


Model60080010001200140016001800
Motor(kw)11*2
18.5*2 35*245*255*275*2110*2

Reducer

P6-P7P7-P8P8-P10P10-P12P11-P13P12-P16P14-P16
                                  Siemens or other motors, planetary reducers or other reducers can be customized according to customer requirements
Rotation Speed8-20rmp
8-20rmp8-15rmp8-15rmp8-15rmp8-12rmp8-12rmp
Blades Diameter220-320260-320260-400400-500400-500500500
Blades materialThe material of the blades (55sicr, 5crsi, 9crsi, skd11, m6v, h13) can be customizedaccording to the customer's actual usage
Feeding Size1200*900mm1400*1000mm1600*1200mm1800*1300mm2000*1300mm2200*1700mm2400*2000mm
                     The size and appearance of the feeding hopper can be customized according to thecustomer's feeding situation
Weight(kg)1800
2500370055007500950013000





Author:Yu Qanqan

Yu Qanqan is a senior engineer of Zhongcheng Machinery Co., Ltd. She has rich theoretical knowledge and working experience in mechanical manufacturing, and has a deep understanding of the relevant industries of waste screening machinery and crushing machinery. She is willing to share the knowledge of screening machinery and crushing machinery.
