Hydraulic baler to help you reduce labor

structure principle：

The hydraulic baler comprises a bracket, which is provided with a bottom plate and a front and rear side baffle plate, a jack is installed on the bracket, the jack is provided with a piston rod, the right end of the piston rod is connected with a vertical pushing plate, the right side of the pushing plate is connected with a pushing plate, and the gap between the adjacent pushing plate is a rope trough on the plate; The upper right part of the support is provided with a press-loading baffle, and the support on the left side of the press-loading baffle is provided with a feed port;

The support on the right side of the front and rear side baffle plates is fixably connected with the front and rear side baffle bars respectively, and the gap between the adjacent side baffle bars is the rope hole; The right end of the support is provided with a discharge port, the right end of the support at the discharge port is hinged with a door plate, the left side of the door plate is connected with a door slat, and the gap between the adjacent door slats is a rope trough on the door; The cavity enclosed by front and rear side baffle, pusher plate and bottom plate is the feeding chamber, and the cavity enclosed by front and rear side baffle, pressure top baffle, door plate and bottom plate is the extrusion chamber. The door panel and the right end of the support are fixed and connected with a locking device. And according to the need to adjust the size of the package within a certain range.

Scope of adaptation:

Universal hydraulic baler is suitable for straw, grass, waste paper packaging, cotton packaging, clothing packaging, straw packaging, plastic packaging, wool packaging, recyclable garbage packaging, It can also be used in cotton, wool, waste carton, waste paper board, yarn, tobacco leaf, plastic, cloth, woven bag, knitting wool, hemp, sack, top, ball, cocoon, silk, hops, waste plastic bag and other light foam, loose materials and other soft materials. Motor series products are widely used in metallurgy, petroleum, chemical industry, machinery manufacturing and other industries; Cotton machine series products are mainly cotton processing equipment and accessories, used in cotton processing plants.

Specific operation steps:

1. Packing: Cut and fold the waste paper, waste cardstock, old books and newspapers, waste boxes and other materials to be packed, and place them at the feed port on the side of the baler.

2.  Clamping: Use the clamping mechanism to clamp the pile.

3.  Selection: Select the binding rope according to the requirements, adapt to the different pressure of the batting head, adjust the position of the cutting knife, can be selected according to different materials. (lashing rope is generally nylon rope)

4.  Compression: Use the start button to compress waste paper. After moving to a certain position, you can manually button it down.

5. Packing: After compression is completed, press the packing button, observe from the top of the machine to see whether the binding is firm, tie the binding rope, and send it to the destination.

6. Cleaning: After packing, clean up the inside and surface of the waste paper baler immediately to keep the machine clean and tidy, so as to ensure the smooth use of the next time.
