Application fields of double shaft shredder

Date:2024-11-29
View: Point

The double-shaft shredder is a mechanical device widely used in the field of recycling and waste management. It uses two relatively rotating blades to tear materials into smaller sizes and is suitable for processing materials of various hardness and toughness. The following are some of the main application areas of the double-shaft shredder:


Waste tire recycling: The double-shaft shredder can effectively process waste tires and break them into small pieces for subsequent processing into recycled rubber, fuel or other uses.

Plastic recycling: For different types of plastic waste, such as plastic bottles, plastic bags, industrial plastic waste, etc., the double-shaft shredder can crush them to a suitable size for reuse or recycling.

Biomass energy processing: Biomass materials including wood waste, garden waste, agricultural and forestry waste, etc. can be pre-processed by the double-shaft shredder to improve energy conversion efficiency.

Electronic waste processing: For discarded electronic products, such as computer casings, wires and cables, etc., the use of a double-shaft shredder can effectively decompose these materials for subsequent metal recycling and other resource recycling.

Domestic waste treatment: In urban domestic waste treatment, double-shaft shredders can be used to crush large pieces of garbage (such as furniture), kitchen waste, etc., which helps to reduce the volume of garbage and improve transportation and treatment efficiency.

Industrial waste treatment: For solid waste generated in some industrial production processes, such as cardboard, cloth, leather scraps, etc., double-shaft shredders are also applicable, which can help reduce the volume of waste and facilitate management and disposal.

Medical waste treatment: For non-infectious medical waste, such as disposable plastic products, packaging materials, etc., double-shaft shredders can also play an important role, reducing the volume by crushing and reducing the treatment cost.

Due to its powerful crushing capacity and wide adaptability, double-shaft shredders have played an important role in many fields such as resource recovery and environmental protection. With the development of technology, its application scope is still expanding.


Model60080010001200140016001800
Motor(kw)11*2
18.5*2 35*245*255*275*2110*2

Reducer

P6-P7P7-P8P8-P10P10-P12P11-P13P12-P16P14-P16
                                  Siemens or other motors, planetary reducers or other reducers can be customized according to customer requirements
Rotation Speed8-20rmp
8-20rmp8-15rmp8-15rmp8-15rmp8-12rmp8-12rmp
Blades Diameter220-320260-320260-400400-500400-500500500
Blades materialThe material of the blades (55sicr, 5crsi, 9crsi, skd11, m6v, h13) can be customizedaccording to the customer's actual usage
Feeding Size1200*900mm1400*1000mm1600*1200mm1800*1300mm2000*1300mm2200*1700mm2400*2000mm
                     The size and appearance of the feeding hopper can be customized according to thecustomer's feeding situation
Weight(kg)1800
2500370055007500950013000
